Cold Storage 2022
Storage Trends for Rapidly Growing Cold Data
～Optical disc storage Grows in Key Market China～

Publication Date: March 2022
Number of pages: 116
Price excluding tax:5500,000 yen (electronic files only)
550,000 yen (hard copy and electronic files)
Report Summary (PDF)

Main contents analyzed in this report

This report provides a detailed analysis of the following topics to show the role, position, importance, and future expansion trends of optical disk storage in cold storage, which accounts for most of the enterprise market.

  • Overall storage market supply trends for SSDs, HDDs, optical disk storage, LTO, etc.
  • Detailed analysis of cold storage trends in the enterprise market
  • Analysis of individual market trends and technology trends for each type of storage and analysis of future capacity supply capabilities to the market
  • Enterprise Market Storage Tier Shifts and Storage Selection
  • Analysis of the relationship between free space capacity and newly shipped capacity in the enterprise cold storage market
  • Trend analysis on the enterprise storage market in China, the main market for optical disk storage
  • Direction of the optical disk storage business with emphasis on profitability and continuity

Optical Disk Storage Application Analysis and Expected Markets Sharpened by Results

The three major applications for optical disk storage are offline archiving, cold storage in data centers, and big data storage, and the potential market size is extremely large. In both BD and AD, offline storage in on-premises is expected to expand steadily, and data center applications are also expected to grow. The expansion of optical disk storage in data centers is still in its infancy in terms of securing a firm position, but the ongoing challenges in the Chinese market highlight its aggressiveness, and this expansion will continue in the near term.
